A graph agent breaks a phone conversation into discrete nodes, each with its own purpose, instructions, and transition rules. Instead of one giant prompt that has to handle everything, you define exactly what the agent does at each step and exactly when it moves to the next one.

Predictable

Conversations follow explicit paths. Every transition is a rule you defined.

Easy to debug

When something breaks, you know which node failed and why.

Easy to update

Change one node without touching the rest of the flow.

Lower cost

Deterministic edges and static nodes skip the LLM entirely.

​
When to use a graph agent

Pick a graph agent when the call has discrete stages with different objectives (greet, qualify, collect, confirm, close), or when you need deterministic transitions (time of day, retry count, external events). For a single-objective agent that just answers questions, a regular simple_llm_agent is enough.

​
Core concepts

​
Nodes

A node is one step in the conversation. Each node has one clear job.
FieldTypeDescription
idstringUnique identifier. Referenced by edges and current_node_id.
promptstringInstruction given to the response LLM when the conversation is in this node.
edgesarrayPossible transitions out of this node.
examplesobjectSample responses per language ("en", "hi"). Guides tone and phrasing.
node_typestring"llm" (default) or "static". See Static Nodes.
static_messagestringRequired when node_type == "static". Pre-cached audio plays at runtime.
repeat_after_silence_secondsnumberAuto-replay the node after N seconds of user silence. Works on LLM and static nodes.
function_callstringForces the response LLM’s tool_choice to this tool when the node is entered (e.g. transfer nodes).
rag_configobjectOptional per-node knowledge base. See Tools & RAG.

​
Edges

Edges define how the conversation moves from one node to the next.
{
  "to_node_id": "order_status",
  "condition": "Customer provides a valid order number"
}
If no edge matches, the agent stays on the current node and re-asks naturally. There are four edge types: LLM (default), expression, unconditional, and event. Full reference on Edges & Routing.

​
Routing

After every customer message, a routing LLM evaluates the available LLM-typed edges on the current node and picks the best match.
Expression and unconditional edges are evaluated before the routing LLM runs. If a deterministic rule matches, the transition fires instantly with zero latency and zero cost. The routing LLM is only invoked when no deterministic rule matches.

​
Where graph agent config lives

All graph-agent fields live inside llm_agent, nested under tools_config in your conversation task:
agent_config
  └── tasks[]
        └── tools_config
              └── llm_agent       ← graph agent config goes here
                    ├── agent_type: "graph_agent"
                    ├── agent_information
                    ├── routing_instructions
                    ├── current_node_id
                    └── nodes[]

​
Top-level fields

FieldDescription
agent_typeMust be "graph_agent" to enable the node-based flow.
agent_informationGlobal system prompt. Persona, language rules, guardrails. Applied to every node.
routing_instructionsPrompt given to the routing LLM. Prepended to every routing request. Supports {variable} substitution from context_data.
current_node_idStarting node when a new call begins.
nodesArray of all node objects.
modelResponse LLM. Defaults to gpt-4.1-mini.
routing_modelRouting LLM. Defaults to gpt-4.1-mini.
routing_max_tokensCap on routing response tokens. Defaults: 250 (non-GPT-5), 150 (GPT-5).
routing_reasoning_effortGPT-5 routing models only. "minimal" / "low" / "medium" / "high".

​
agent_information is the identity layer

This prompt is applied to every node. Use it for persona, response rules (max sentence count, language switching), pronunciation rules, and hard guardrails.
agent_information is sent with every LLM call. Keep it focused. Save specifics for individual node prompts.

​
Writing effective node prompts

A well-written prompt includes the node’s purpose, the exact question to ask, validation rules, a fallback, and any voice formatting rules. Weak:
Get the order number from the customer.
Strong:
Collect the customer's 10-digit order number.

ASK: 'Can you please share your 10-digit order number?'

VALIDATION:
- Accept only numeric input, exactly 10 digits.
- Expand spoken phrases: 'double four' becomes 'four four'.
- If the customer gives fewer or more digits, ask once more politely.
- After 2 failed attempts, offer to transfer to a live agent.

FORMAT: Confirm the number in groups of 3-3-4 with a short pause between groups.
Spell each digit as a word. Never use numerals in speech.
One node, one job. A node that collects an order number should only collect the order number. Don’t also ask for the customer’s name or call reason in the same node.

​
Next steps

Edges & routing

Edge types, expression operators, built-in variables, inline data extraction.

Static nodes

Pre-cached audio messages with auto-replay on user silence.

Event injection

Drive transitions and proactive speech from external events via REST.

Tools & RAG

Call transfer, custom API tools, per-node knowledge bases.

Debugging

Routing logs, common scenarios, and how to fix them.

Full example

Complete annotated JSON skeleton showing every feature end-to-end.
